Home ProductsSmart Card152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm
152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm
152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm
152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm 152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm
Contact Now

152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : 200pcs/box, 10boxes/carton; For standard size card or customized boxes or cartons as required. Delivery Time : 7 week days
Payment Terms : T/T Supply Ability : 100,000 pcs per week
Place of Origin: China Brand Name: Wisecard Technology
Certification: ISO14443,7816 Model Number: CIU9872B

Detail Information
CPU: 32 Bit Main Frequency: 72MHZ
Timer: 2 * 16/32bit Timer EEPROM: 152KB
Interface 7816: Comply With ISO/IEC 7816 T=0/1 Standard; Supports Up To 446400bps Interface 14443: Comply With ISO/IEC 14443 TYPE A Standard
Interface I2C: Supports Master-slave Mode, Support 400KHZ Interface GPIO: 2
High Light:

Security Algorithm emv card security chip

,

152KB emv card security chip

Product Description

ISO/IEC 14443 TYPE A standard Interface Security Algorithm EMV Chip

Product Description:

CIU9872B_01 Plus chip uses 32-bit secure CPU core and EEPROM memory, supports hardware cryptographic algorithms (DES/AES/ECC/RSA/SHA-n, SM1/SM2/SM3/SM4), supports multiple interfaces: 7816/14443/ I2C / GPIO, for financial applications. EMV originally stood for Europay, Mastercard, and Visa, the three companies that created the standard. The standard is now managed by EMVCo, a consortium with control split equally among Visa, Mastercard, JCB, American Express, China UnionPay, and Discover.



Specification:

CPU Security Features
CPU 32 bit Security algorithm supports DES/3DES/AES
Main frequency 72MHZ supports SM1/SM4/SM3
Timer 2 * 16/32bit Timer supports RSA/ECC/SM2
　 　 Random
number		 Supports true random number, in line
with AIS31-P2 standard
Memory Memory Supports memory security protection
mechanism
EEPROM 152KB Sensor Supports multiple safety sensor
detection
Erasing and writing
≥ 500,000 times		 Active shield support
Data storage time
≥ 25 years		 Unique serial
number		 The unique serial number of the chip
cannot be changed
　 　 Self-check
function		 Support self-check safety reset
　 　 　 　
Interfaces 　 Package Form
7816 Comply with ISO/IEC 7816
T=0/1 standard		 Module
Package		 Dual interface
Supports up to 446400bps 6PIN Silver/Gold
14443 Comply with ISO/IEC 14443
TYPE A standard		 Applications
Supports up to 848Kbit/s EMV standard payment
I2C Supports master-slave mode,
support 400KHZ		 1)Supports VISA(VSDC2.8.1g1)+ Mastercard
(MChip Advance 1.2.3)Dual APP
GPIO 2
Electrical Characteristics 　
Operating
Voltage		 1.6V～5.5V 2)Supports Mastercard(MChip Advance 1.2.3)
Operating
temperature		 -25℃~85℃
ESD 7816interface 6KV(HBM)
14443interface 4KV(HBM) 　



Service:

1. QC: Every single card will be carefully checked by machine or manual work before dispatched.

2. Accept personalized customization.

3. Strict quantity control on processing.

4. On time delivery.

5. Quality assurance: 1year warranty after delivery.

6. Quick response: Your inquiry will be replied in 24 hours.





FAQ:

Q: Do you have the items in stock?
A: Yes, the item are large stock. We can send the goods out within 3 days after payment received. For the goods are out of stock, production time is about 7-10 days.


Q: Do your products support customized?
A: Yes, we provide OEM service. Our standard products can be branded according to your needs. The color tones, finishing, logo silkscreen can all be customized to give the products in line with your company image and style.


Q: What about minimum order quantity?
A: We have no limit for MOQ, 1 piece is available.





152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm 0152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm 1152KB EMV Card Security Chip TYPE A Standard 7816 14443 Interface Security Algorithm 2
