Handheld Wireless 2D Barcode Scanner 2.4g Memory 640x480 CMOS Sensor

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : packing details: standard export carton, can be customized. port: Shen Zhen ports Delivery Time : 7 work days
Payment Terms : T/T Supply Ability : 100,000 pcs per week
Place of Origin: China Brand Name: Wisecard
Certification: SGS/ROHS/CE/ISO/CE RED Model Number: barcode scanner

Detail Information

Imaging Sensor: 640*480 CMOS QR Code: PDF 417、Micro PDF 417、Micro QR, DataMatrix、QR、Aztec
System Compatibility: Linux、Android、WindowsXP、7、8、10、MacOS Anti-fall: Can Withstand 2 Meters Free Fall 5 Times
Operating Voltage: 5V Communication Interface: USB Port (drive-free), USB Virtual Serial Port (install Drive), Serial Port (drive-free)
The Length Of The Data Line: 180CM(±3CM)
High Light:

Handheld 2D Barcode Scanner

,

Wireless 2D Barcode Scanner

,

Wireless Barcode Scanner UPC 13mil

Product Description

2d Bar Code Reader Receiver Handheld Wireless 2.4g With Memory Inventory Barcode Scanner Gun With Charge Base​

Description Of Smart Scanner

1. Support blue tooth+wireless communication methods,and switch mode by press/hold button 10seconds.

2. Data transmission,blue tooth ≤50M, 2.4GHz≤100M

3. With Charging base can be used for charging and placing barcode scanner.

4. Indicator lights of different colors d indicate different states.

5. Support 1d+2d+QR+ pdf417+Data matrix etc almost all bar codes.

6. With 2200mAH battery and 2MB memory.

7. Factory direct sale, highly cost-effective.



Feature Of Smart Scanner

1. With 640*480CMOS Imaging sensor

2. Buzzer: Start prompt, decode success prompt

3. Support Turkish, Greek, Belgian, French, British-English

4. Anti-fall: Can withstand 2 meters free fall 5 times



Specification
Imaging sensor 640*480CMOS
Decode type One dimensional code EAN-8,EAN-13,EAN-132add-on,EAN-135add-on,ISSN,ISBN,UPC-A,UPC-E,Code 11Code 32,Code 39,Code 39 FULL ASCII,Code 93,Code 128,Codabar,Industrial 2 of 5,Interleaved 2 of 5,Matrix 2 of 5,IS BT-128,GS 1-128,GS1DataBar(RSS 14) ,GS1DataBar Limited,GS1DataBar Expanded
QR code PDF 417,Micro PDF 417,Micro QR, DataMatrix,QR,Aztec
Scanning area Test the barcode Minimum range Maximum range
UPC-13mil 4cm 35cm
20mil code 39 7cm 50cm
20mil QR Code 2cm 30cm
System compatibility Linux,Android,WindowsXP,7,8,10,MacOS
Supported keyboard American-English, French, Italian, German, Spanish, Finnish, Japanese, Russian, Arabic, Irish, Bo, Dutch, Czech, Portuguese (Portuguese, Brazilian), Swedish, Turkish, Turkish, Greek, Belgian, French, British-English
The type of barcode that can be swept Film 1D and 2D bar code;
Identify the angle range The corner ± 360 degrees, the elevation ± 60 degrees, and the angle ± 70 degrees
Anti-fall Can withstand 2 meters free fall 5 times
Waterproof and dustproof IP54 compliant
Operating temperature range -20-55°C
Save the temperature range -20-60°C
Light Blue power LED, decoded flashing
Buzzer Start prompt, decode success prompt
Keystroke Trigger the scan
Net weight of the host 100g
Includes packing and accessory weight 300g
Host size (length, width, height mm 168mm*85mm*62mm
Package size (length, width, height mm) 240*140*89mm
The length of the data line 180CM(±3CM)
Communication interface USB port (drive-free), USB virtual serial port (install drive), serial port (drive-free)
Operating voltage 5V



Application Of Smart POS Terminal

1. Retail

2. Restaurant& hospitality

3. Field services

4. Warehouse &manufacturing
